WHEEL AND Tyre equipment

- ARC (Absolute Run-Flat Compatibility)
- QuadraClamp system
- Rim clamping from outside: 10” to 24”
- Rim clamping from inside: 12” to 26”
- Max. tyre diameter 43” (1100 mm)
- Max. tyre width 16” (415 mm)
- Air Pressure 8 to 10 bar
- Bead breaker cylinder force at 10 bar 30800 N (3140 kg)
- Power Supply 220v 1ph 50HZ - 1 speed (Optional 400v 50HZ 3ph1 speed)

- Split Weight Function
- Virtual Sonar
- Stealth' Display Panel
- Standard Clamping: 40mm diameter
- Display: Digital
- Rim Width: 1.5"-20"
- Rim Diameter: 10"-30"
- Maximum Wheel 1200mm
- Diameter:
 - Maximum Wheel Width: 530mm
 - Maximum Wheel Weight: 75kg
- Rotation: 100rpm
- Power Supply: 240V
- Available with optional wheel guard

- Laser point Accuracy
- OWB (one Weight Balancing)
- Split Weight Function
- Max. Wheel Weight: 70kg
- Max. Wheel Diameter: 1200mm
- Max. Wheel Width: 530mm
- Rim Diameter: 10-30"
- Rim Width: 1.5"-20"
- Revolutions: 100rpm
- Max. tyre width: 16" (415mm)
- Power Supply: 115-230V/50/6OHZ/
- 1Ph/50OW

- Automatic
- HP3 assist arm
- Locking Rim Dimensions 10"-24"
- Max. Tyre Diameter 1000mm (39")
- Plus Max. Tyre Width 340mm (13")
- Force on Bead Breaker Blade (10 bar) 30800N
- Working Pressure 10 bar (145 psi)
- Inflating Pressure Limiting Device Max. 3,5 bar (50 psi)
- Power Supply Voltage 230/400V 3ph Motor Power 0.55 kW
- Max. Spindle Torque 1150 NM
- Dimensions 1120mm x 1580mm x 1890mm
- Noise Level in Working Conditions <70 dB(A)

- Split Weight Function
- Automatic data input for the offset and diameter measurements
- Protection Class: IP 54 Max.
- Single-phase Power Supply: 230V 50/50 Hz
- Power Consumption: 0,12 Kw
- Cycle Time of Wheel: 6 sec. (5 3/4"x14") 15 kg
- Balancing Precision: ±1g
- Average Noise: <70dB (A)
- Rim Width Setting Range: 1.5” – 20” or 40mm – 510mm
- Diameter Setting Range: 10"-30" or 265mm-765mm
- Maximum Wheel Weight: <75kg
